EN853 SAE 100 R6 Wire Braid Hydraulic Hose Oil Air Water Textile Rubber Hose

Product Categories

Shaanxi Kelong New Materials Technology Co., Ltd.

Contact Now

Name: EN853 SAE 100 R6 Wire Braid Hydraulic Hose Oil Air Water Textile Rubber Hose
Brand: Kelong
Price: 1 USD

Brand Name : Kelong

Model Number : KS1706-2

Certification : ISO9001 / IRIS

Place of Origin : China

Payment Terms : L/C, T/T, Paypal

Supply Ability : 16,5600 meters /months

Delivery Time : 7-15 days

Name : Wire Braided Hydraulic Hose

Tube : Synthetic Rubber, Resistant Against Hydraulic Fluids

Reinforcement : One Braids Of High Tensile Steel Wire

Temperature range : -40°C to 100°C / -40°F to +212°F (max 120°C / 248°F intermittent)

Note : Various Covers Available

Cover : Abrasion And Ozone Resistant Synthetic Rubber

Applications : Petroleum Based Hydraulic Oil

Contact Now

Wire Braid Hydraulic Hose Meets SAE 100 R6

Hose Construction

Inner Tube: Black oil resistant synthetic rubber

Reinforcement: One braids of high tensile super flexible steel wire

Outer Layer: Black oil, weather, and abrasion resistant synthetic rubber

Note: Various covers available

Temperature range: -40°C to 100°C / -40°F to +212°F

Applications:Suitable for convey water-based, petroleum-based, and biodegradable hydraulic oil.

SAE 100 R6 textile braided hydraulic hose
Hose code	Size		Dash size	ID		OD	Working pressure		Proof pressure		Min burst pressure		Min bending	Weight
	Size			ID		OD	Working pressure		Proof pressure		Min burst pressure		Min bending	Weight
	mm	inch		min	max	max	MPa	psi	MPa	psi	MPa	psi	mm	kg/m
SAE100R6-01	5	3/16	-3	4.2	5.4	10.3	3.5	510	7	1015	14	2030	50	0.1
SAE100R6-02	6.3	1/4	4	5.6	7.2	11.9	2.8	410	5.6	810	11.2	1620	65	0.13
SAE100R6-03	8	5/16	5	7.2	8.8	13.5	2.8	410	5.6	810	11.2	1620	75	0.15
SAE100R6-04	10	3/8	6	8.7	10.3	15.1	2.8	410	5.6	810	11.2	1620	75	0.18
SAE100R6-05	12.5	1/2	8	11.9	13.5	19	2.8	410	5.6	810	11.2	1620	100	0.26
SAE100R6-06	16	5/8	-10	15.1	16.7	22.2	2.4	350	4.8	710	9.8	1420	125	0.34
SAE100R6-07	19	3/4	-12	18.3	19.9	25.4	2.1	310	4.2	610	8.4	1220	150	0.4

EN853 SAE 100 R6 Wire Braid Hydraulic Hose Oil Air Water Textile Rubber Hose

Product Tags:

EN853 Textile Rubber Hose
